REINSTALLATION INSTRUCTIONS FOR THE LENS AND AUTOMATIC FILTER
1. Slide the automatic filter (K) through the filter frame and set
it back into the holding tray.
2. Lock the filter frame screw (I) by turning the screw clockwise.
Do not overtighten the nut or the threads may become stripped.
6
3. Place outer protection lens (J) back into the front of the
helmet by inserting one side of the lens into either side
slot and then bend the lens just enough that it will slip into
the other side slot.
1
K
H
3
J
2
I
