REPLACEMENT PARTS LIST - SAW (PART A)
I.D. Description Size Q’ty I.D. Description Size Q’ty
X4NP MOTOR ASS’Y 1 X4PY DUST BAG 1
X4P0 CR. RE. PAN HD. SCREW M5*55 1 X4PZ LASER COVER 1
X4P1 BATTERY (AAA) 2 X4Q0 LASER LABEL (LEFT) 1
X4P2 BATTERY BOX 1 X4Q1 CR. RE. COUNT HD. SCREW M4*8 7
X4P3 BUTTON SWITCH 1 X4Q2 ANTI-DUST PLATE 1
X4P4
CR. RE. PAN HD. TAPPING
SCREW
ST3.9*14 2 X4Q6 HEX. SOC. SET SCREW M6*10 2
X4P5 CORD CLAMP 1 X4Q7 COMPRESSION SPRING 1
X4P6 POWER CABLE 1 X4Q8 CLAMP BOLT 1
X4P7 GUARD-CORD 1 X4QL LABEL 1
X4P8 MOTOR HANDLE (DOWN) 1 X4QY CR. RE. PAN HD. SCREW M4*12 1
X4P9 BUTTON SWITCH 1 X4QZ BLADE 1
X4PA LIMIT SWITCH 1 X4R0 ARBOR COLLAR 2
X4PB TRIGGER 1 X4R1 ARBOR BOLT M8*16 1
X4PC MOTOR HANDLE (TOP) 1 X4R2 CUTTER SHAFT GUARD 1
X4PD
CR. RE. PAN HD. TAPPING
SCREW
ST3.9*16 4 X4R3 CR. RE. PAN HD. SCREW M6*10 1
X4PE BLADE WRENCH 1 X4R5
CR. RE. PAN HD. ROUND
NECK SCREW
M6*9 1
X4PF LASER SWITCH 1 X4R6 SPRING GUARD 1
X4PG BATTERY COVER 1 X4R7 LOCK NUT M6 2
X4PH LABEL 1 X4R8 PC-GUARD 1
X4PL CR. RE. PAN HD. SCREW M5*30 1 X4R9 BRACING PLATE 1
X4PP CABLE SHELL 1 X4RA LEVER 1
X4PQ LABEL 1 X4RC COLLAR 1
X4PR WAVE WASHER φ5 2 X4RD CR. RE. COUNT HD. SCREW M6*20 1
X4PS LASER SET 1 X4RQ FLAT WASHER φ6 3
X4PT FLAT WASHER φ3 2 X4S6 SPECIAL SCREW M6*12 2
X4PU CR. RE. PAN HD. SCREW M3*8 2 X4S7 WAVE WASHER φ8 1
X4PV HEX. SOC. SET SCREW M4*6 1 X4SX CROSS PAN HEAD SCREW M5*40
1
X4PW LASER ASS’Y 1 X4XK COMPRESSION SPRING
1
X4PX LASER LABEL (RIGHT) 1
To Next Page
