KODAK CAROUSEL® Slide Projector 17
Operation
Clearing a Gate Jam
To remove a defective slide or foreign object stuck in the projector gate, you
need to remove the tray.
• Slide the tray release latch in the direction of the arrow, and
• with your other hand, lift off the back of the tray.
With the lock ring firmly in place,
turn the 140-slide tray upside
down. Retract the tray release
latch in the direction of the arrow
and align the index hole with the
index notch. (For an 80-slide tray,
rotate the metal plate until it locks
into position.) Put the tray aside.
Remove the slide orobject fromthe
projector gate by pressing the
forward button or removing the
slide manually.
Remount damaged slides to protect
your projector and slides from
subsequent damage.
