Menu Summary List (Legend: ● First level submenu, ○ second level submenu, ◊ third level submenu)
Metering Menu (Continued)
Generator Information Menu (Continued)
• Generator Metering
o L1-L2 VOLTS: ###V
o L2-L3 VOLTS: ###V
o L3-L1 VOLTS: ###V
o AVG GEN VOLTAGE L-L: ###V
o GEN FREQUENCY: ##.#Hz
o L1-L0 VOLTS: ###V
o L2-L0 VOLTS: ###V
o L3-L0 VOLTS: ###V
o AVG GEN VOLTAGE L-N: ###V
o GEN FREQUENCY: ##.#Hz
o L1 CURRENT: ###A
o L2 CURRENT: ###A
o L3 CURRENT: ###A
o AVG CURRENT: ###A
o GEN FREQUENCY: ##.#Hz
o L1 POWER: ####W
o L2 POWER: ####W
o L3 POWER: ####W
o TOTAL POWER: ####.#kW
o GEN % OF RATED kW: ###%
o L1 REACTIVE POWER:
####VAR
o L2 REACTIVE POWER:
####VAR
o L3 REACTIVE POWER:
####VAR
o TOTAL REACTIVE POWER:
####VAR
o L1 APPARENT POWER:
####VA
o L2 APPARENT POWER:
####VA
o L3 APPARENT POWER:
####VA
o TOTAL APPARENT PWR:
####VA
o GEN % OF RATED kVA: ###%
o L1 PF: #.##
o L2 PF: #.##
o L3 PF: #.##
o TOTAL PF: #.##
o GEN PHASE ROTATION: ###
• Engine Metering
o ENGINE SPEED: ####RPM
o ECM BATTERY VOLTAGE:
##.#VDC
o GEN BATTERY VOLTAGE:
##.#VDC
o GENSET CONTROLLER
TEMP: ###°F
o OIL PRESSURE: ###PSI
o OIL TEMPERATURE: ###°F
o COOLANT TEMPERATURE:
###°F
o COOLANT PRESSURE: ###PSI
o FUEL LEVEL: ###%
o FUEL PRESSURE: ###PSI
o FUEL TEMPERATURE: ###°F
o FUEL RATE: ###GAL/h
o (shown if available from ECM)
o FUEL USED LAST RUN: ###GAL
o (shown if available from ECM)
o CRANKCASE PRESSURE: ###PSI
o INTAKE AIR PRESSURE: ###PSI
o INTAKE AIR TEMP: ###°F
• Battery X Meter
Note:
This menu option does not apply
to marine generator sets.
o STATUS: (IDLING/STANDBY/
o CHARGING/ BATT
FAIL/CHRGR FAIL/ NOT
AVAILABLE)
o OUTPUT VOLTAGE: ##.#VDC
o OUTPUT CURRENT: ##.#A
o CHARGER STATE:
IDLE/BULK/
o ABSORB/FLOAT/EQUAL/
o REFRESH/ RECOVER/NA
o CHARGER TEMP: ###°F
o REDUCED OUTPUT ACTIVE:
YES/NO
o TEMP COMPENSATION
ACTIVE: YES/NO
o SOFTWARE VER.:
XXXXXXXXXXXX
• Overview
o GENERATOR STATUS
◊ AVG GEN VOLTAGE L-L: ##V
◊ AVG CURRENT: ###A
◊ GEN FREQUENCY: ##.#Hz
o ENGINE STATUS
◊ COOLANT TEMPERATURE:
###°F
◊ OIL PRESSURE: ###PSI
◊ GEN BATTERY VOLTAGE:
##.#V
o SYSTEM STATUS
◊ FUEL PRESSURE: ###PSI
◊ TOTAL POWER: ####kW
◊ TOTAL RUN TIME: #####.#hrs
• Paralleling Metering
o CONNECTED TO BUS:
TRUE/FALSE
o AVG BUS VOLTAGE L-L: ###.#V
o AVG GEN VOLTAGE L-L: ###.#V
o BUS FREQUENCY: ##.##Hz
o GEN FREQUENCY: ##.##Hz
o BUS TOTAL POWER: #####.#kW
o BUS % OF RATED kW: ###%
o BUS % OF RATED kVAR: ###%
o LAST MAINTENANCE:
##/##/####
o OP HRS SINCE MAINT: ####hrs
o STARTS SINCE MAINT: ###
o ENG HRS SINCE MAINT:
####hrs
o LOADED SINCE MAINT: ####hrs
o UNLOADED SINCE MAINT:
####hrs
o kW HRS SINCE MAINT: ####kWh
o RESET MAINT RECORDS:
YES/NO*
o LAST START: ##/##/####
o LAST RUN LENGTH: ####hrs
o CTRL SERIAL #: XXXXXXXXX
o SOFTWARE VER.: XXXXXXXXX
o ECM SERIAL #: XXXXXXXXX
o GENSET MODEL #: XXXXXXXXX
o GENSET SPEC. #: XXXXXXXXX
o GENSET SERIAL #: XXXXXXXXX
o ALT. PART #: XXXXXXXXX
o ENGINE PART #: XXXXXXXXX
o ENGINE MODEL #: XXXXXXXXX
o ENGINE SERIAL #: XXXXXXXXX
• Event History
o GENERATOR EVENT HISTORY
##/##/#### (Date) ##:##.##XX
(Time) DEVICE EVENT: ###
STATUS/FAULT/NOTICE/
WARNING EVENT X OF Y
o ENGINE EVENT LOG
SPN: ####
FMI: ##
OCCURRENCE COUNT: ###
EVENT X OF Y
• Configuration
o GENERATOR CONFIGURATION
◊ OPERATING MODE:
(STANDBY/PRIME)
◊ APPLICATION TYPE:
(NONE/MARINE/
MOBILE/STANDBY/PRIME)
◊ SYSTEM VOLTAGE L-L:
###V*
◊ SYSTEM FREQUENCY:
##.#Hz*
◊ SYSTEM PHASE:
(SINGLE/SINGLE
DOG/THREE-WYE/THREE-
DELTA)*
◊ RATED ENGINE SPEED:
####RPM
◊ ENGINE SPEED
ADJUSTMENT: *
◊ ADJUSTED ENGINE RUN
SPEED:
####RPM
Generator Information Menu
• Generator Information
o TOTAL RUN TIME: #####.#hrs
o HOURS LOADED: #####hrs
o HOURS UNLOADED: #####hrs
o kW HOURS: #####kWh
o OPERATING HOURS: ######hrs
o TOTAL # OF STARTS: ########
* User-Defined (changeable) Menu Displays. Use SiteTech™ software to change other settings including User-Defined Menu Displays.
