Kohler 38RCLA Operation

TP-6810 7/16 35Section 3 RDC2 Controller Operation
3.8 Overview Menu
Overview ---->
1.2 h
Active Alert
(if any)
tp6809
Genset Status
Standby
Voltage: 240V
Freq: 60.0Hz
Engine: 95F
Oil: 40 PSI
Battery
12.3V
Engine Runtime:
27.4 h
Date: 02DEC2011
Time: HR:MNpm
Next Exercise:
09:00p 09Dec2011
Next Maintenance:
150 h or Mar2012
SW Version:
4.03
<---- Return
Figure 3-8 Overview Menu
3.9 Engine Metering Menu
The engine metering menu displays engine status
information as shown in Figure 3-9. This menu displays
status information only. No settings can be changed
from this menu.
tp6810
Eng Speed:
1800 RPM
Coolant Temp:
73 F
Battery:
12.3 V
<---- Return
Engine ---->
Metering
Oil Pressure:
40 PSI
Oil Temp:
73 F
Figure 3-9 Engine Metering Menu
