Kohler Co. 11 1383682-A01-C
SPECIFICATIONS /
規格
/
사양
Water pressure
Min water pressure 0.07MPa (dynamic pressure)
Max water pressure 0.74MPa
Rated voltage Refer to "Table 1"
Rated power* 1100W
Product outline dimensions About 530mm*430mm*120m
Weight of product About 4.5kg
Cleaning
Rear wash Yes, adjustable dials
Front wash Yes, adjustable dials
Flow rate
(when pressure is 0.2MPa)
The max dial of rear wash not lower than
500ml/min
Spray water temp adjustment
OFF, adjust 3 dials (ambient temp, about 31-39℃ )
Single spray duration (Max)
About 5min
Safety
device
Water overheat
protection
Thermal fuse
Counter-flow
prevention
Check valve (only available to
C3-430/C3-400/C3-400S for Taiwan)
Comfort
Heated
seat
Temp adjustment
OFF, adjust 3 dials
Safety device Thermal fuse
Cover Buffering
Seat Buffering
Sanitary
Wand self-cleaning Yes
Quick-release body Push release button
Anti-bacterial materials Seat, cover
UV sanitizing Yes (K-22445TW-0 only)
Other
functions
Control panel On the side of the unit
Seat switch Located inside the seat
Lighting Yes K-22445TW-0 only)
*Power value shall be checked under the following conditions: dynamic pressure 0.2MPa, inlet
water temp 15℃ .
The above parameters are for the full-functional version. For differences in the specifications of
models, refer to their product configuration tables.
