Kohler Command Pro ECV850 User Manual

Specifi cations
1119 690 01 Rev. --
KohlerEngines.com
TORQUE SPECIFICATIONS
3,5
ECV850 ECV860 ECV870 ECV880
Governor (Electronic)
Governor Control Unit (GCU) to GCU Bracket Screw 3.1 N·m (27 in. lb.)
GCU/Control Bracket to Manifold Screw 10.2 N·m (90 in. lb.)
Digital Linear Actuator (DLA) Bracket to GCU Bracket Nut 10.2 N·m (90 in. lb.)
DLA to DLA Bracket Screw 4.1 N·m (35 in. lb.)
Governor (Mechanical)
Lever Nut 7.1 N·m (63 in. lb.)
Ignition
Spark Plug 27 N·m (20 ft. lb.)
Coil Fastener 10.2 N·m (90 in. lb.)
Crankshaft Position Sensor Fastener 8.2 N·m (73 in. lb.) into a new hole
7.7 N·m (68 in. lb.) into a used hole
Electronic Control Unit (ECU) Fastener 5.6 N·m (50 in. lb.)
Rectifi er-Regulator Fastener 5.6 N·m (50 in. lb.)
Muffl er
Retaining Nut 27.8 N·m (246 in. lb.)
Bracket Fastener 16.0 N·m (142 in. lb.)
Oil Cooler (Optional)
Fastener
Top (M5)
Bottom (M6)
5.6 N·m (50 in. lb.)
4.8 N·m (50 in. lb.)
Oil Pan
Fastener 25.6 N·m (227 in. lb.)
Oil Drain Plug 21.4 N·m (15.7 ft. lb.)
Oil Temperature Sensor 7.3 N·m (65 in. lb.)
Oil Sentry
TM
Pressure Switch 9.0 N·m (80 in. lb.)
Oil Pump Cover Fastener 11.3 N·m (100 in. lb.) into new holes
7.8 N·m (69 in. lb.) into used holes
Solenoid (starter)
Mounting Hardware 4.0-6.0 N·m (35-53 in. lb.)
Nut, Positive (+) Brush Lead 8.0-11.0 N·m (71-97 in. lb.)
Starter Assembly
Thru Bolt 5.6-9.0 N·m (49-79 in. lb.)
Mounting Screw 16.0 N·m (142 in. lb.)
Brush Holder Mounting Screw 2.5-3.3 N·m (22-29 in. lb.)
Stator
Mounting Screw 9.3 N·m (82 in. lb.) into new holes
4.0 N·m (35 in. lb.) into used holes
Valve Cover
Fastener 10.9 N·m (96 in. lb.)
3
Values are in Metric units. Values in parentheses are English equivalents.
5
Lubricate threads with engine oil prior to assembly.
