2. Install the Faucet
IMPORTANT! When mounting the faucet to uneven surfaces, such
as tile grout lines, apply a suitable sealant in addition to the gasket
provided. The sealant will reduce the risk of water seepage under
the faucet.
Slide the escutcheon and gasket to the spout.
Partially thread two screws into the threaded ring until they
protrude slightly from the backside of the threaded ring.
Apply thread sealant to the spray hose outlet threads.
Slide the threaded ring and metal washer onto the handspray
hose.
Run the handspray hose up through the spout mounting hole,
then connect and tighten the handspray hose to the spray hose
outlet.
Position the spout in the desired mounting position.
Slide the metal washer onto the shank from the underside of the
sink.
Thread the ring up the shank until it is about 1/4″ (6 mm) away
from the underside of the sink. Ensure the screw holes face the
front and back of the faucet.
Tighten the screws.
Spout
Handspray
Sink
Escutcheon
Washer
Ring
Screws
Gasket
Spray Hose
Outlet
1036178-2-F 4 Kohler Co.
