3. Install the Mounting Plate
Position the mounting plate over the mounting holes on the bowl.
Position the washers to rest in the mounting plate grooves.
For toilets with threaded mounting holes: Insert the bolts
through the washers and thread into the mounting holes. Do not
fully tighten at this time.
For all other installations: Insert the bolts through the washers
and into the mounting holes. Thread a nut, gasket, and flat
washer onto each bolt. Do not fully tighten at this time.
Mounting Plate
Bolt
Washer
Nut
Gasket
Flat
Washer
Kohler Co. 7 1321454-2-B
