Cleaning the Screen
NOTE: Clean the filter screen every 6 months or when there is a
reduction in the maximum water flow from the spray wand.
Turn off the water at the supply stop.
Press the release button to disengage the seat from the mounting
bracket. Refer to the ″Removing the Seat″ Section.
Slide the seat forward to allow access to the hose inlet.
Disconnect the water supply hose from the seat connection.
Using long-nosed pliers, carefully remove the filter screen from
the inlet.
Clean the filter screen with a soft-bristled brush.
Reinstall the filter screen.
CAUTION: Risk of product damage. Do not cross-thread the hose
connection to the inlet.
Reconnect the water supply hose to the inlet, one-quarter turn
past hand tight.
Reinstall the seat.
Turn on the water supply.
Check all connections for leaks, and make any adjustments as
needed.
Filter Screen
Inlet
1381632-5-A 12 Kohler Co.
