KOMATSU
HD785-7 Dump Truck
PARTS LIST – RETURN AIR MODULE
Item No.
Part No.
Rev
Description
Qty
Material
Thickness
Colour
Category
1
100138R02
0
R.A.F. Filter Base
1
-
-
Charcoal Satin 27288351
Weld Assy
2
100138-R875
0
R.A.F. Frame
1
Zan
1.5
Charcoal Satin 27288351
RAF Frame
3
500016
[*]
HEPA Filter 285 x 165 x 31
1
N/A
-
-
HEPA Filter
4
300814
-
M6x20 Scallop Knob Male
4
-
-
-
Hardware
