10.
Check the filter seal surface for fuel leakage.
If there is any leakage of fuel, check the tightening condition of the filter cartridge.
If there is still leakage of fuel, follow steps 2 and 3 to remove the filter cartridge, then check the packing
surface for damage or foreign material. If any problem is found, replace the cartridge with a new one, then
repeat steps 4 to 10 to install the filter cartridge.
REMARK
When bleeding air, air may remain inside of the water separator. However, the engine can be started after
pumping feed pump (4) in and out until it becomes heavy. Leave it as it is for a while after stopping the engine,
and air is bled spontaneously.
METHOD FOR CLEANING TRANSFER CASE BREATHER
1.
Loosen the bolts (1) (3 pieces) and remove the cover (2).
2.
After removing dirt and dusts around the breather (3), re-
move the breather (3) and immerse it in detergent liquid to
clean.
While the breather is removed, use care to prevent entry of
dusts through the mounting location of the breather.
METHOD FOR CHANGING OIL IN TRANSFER CASE AND CLEANING TRANSFER
CASE STRAINER
WARNING
• Immediately after the engine is stopped, its parts and oil are still very hot and may cause burn in-
jury. Wait for the temperature to go down, and then start the work.
• When removing the oil filler cap, the oil may spurt out. Turn it slowly to release the internal pres-
sure, then remove it carefully.
Refill capacity: 7.0 ℓ
Items to be prepared
• Container to catch the drained oil
MAINTENANCE MAINTENANCE PROCEDURE
4-61
