Konica Minolta Ultra KDR User Manual

Ultra KDR Panel Configuration and Calibration Guide v1.1
Ultra
5
Customer Support 1.800.366.5343 – HCITsupport@konicaminolta.com
VZ0099HTG201606-1.1
1.3.2 Panel registration
1. Launch Ultra.
For detailed Ultra software information refer to Ultra DR
Quick Guide and or the Ultra UAI Admin Guide.
2. Click Options.
3. On the Device Configuration tab, under
Device Identity section, enter the Panel
serial number (Figure 6). You can find this
number located on the back of the panel.
Figure 6 Device configuration
4. Click Manual Registration to launch the
Konica Minolta Aero SDK Setting Tool
(Figure 7).
The KONICA MINOLTA AeroSDK Setting
Tool is used to register all devices in
conjunction with the KDR Panel. The IF
Cable, Panel and XG-IF Box registration
must be completed before use.
Figure 7 KONICA MINOLTA AeroSDK Setting Tool
