621T, 621R - Defining the 621T, 621R DVI Optical Transmitter/Receiver
4.2 Defining the 621R DVI Optical Receiver
Figure 2: 621R DVI Optical Receiver
Connects to the DVI acceptor
12V DC connector for powering the unit
Lights when receiving power
Lights when receiving a stable DVI signal
Connect to the optic connectors on the 621T
Connects to the DDC RJ-45 connector on the 621T
using a UTP CAT5 cable with RJ-45 connectors at both
ends (the PINOUT is defined in Section 5.3
