KTM 125 EXE 2001 User Manual

ENGLISH
31
Collar nut front wheel spindle M 16x1,5 40 Nm (30 ft.lb)
Brake caliper front M 8 25 Nm (19 ft.lb)
+ Loctite 243
Clamping screws upper fork bridge M 8 20 Nm (15 ft.lb)
Clamping screws lower fork bridge M 8 15 Nm (11 ft.lb)
Clamping screws fork stubs M8 10 Nm (7 ft.lb)
Collar nut rear wheel spindle M 20x1.5 80 Nm (59 ft.lb)
Hexagon nut swing arm bolt M 14x1.5 100 Nm (74 ft.lb)
Collar screw handlebar clamp M 8 20 Nm (15 ft.lb)
Allen head screw handlebar support M 10 40 Nm (30 ft.lb)
+Loctite 243
Shock absorber top M 12 60 Nm (44 ft.lb)
Shock absorber bottom M 12 60 Nm (44 ft.lb)
Screw adjusting ring spring preload M 6 8 Nm (6 ft.lb)
Other screws on chassis M 6 10 Nm (7 ft.lb)
M 8 25 Nm (19 ft.lb)
M 10 45 Nm (33 ft.lb)
TIGHTENING TORQUES - CHASSIS 125 EXE/SM
* Dead-weight without fuel
WP 1218T715
Compression adjuster 3
Rebound adjuster 14
Spring PDS1–250
Spring preload 5 mm (0.2 in)
STANDARD ADJUSTMENT - SHOCK ABSORBER
WP 0618T777A
Compression adjuster 10
Rebound adjuster 9
Spring 4,2 N/mm
Spring preload 10 mm (0.4 in)
Air chamber length 140 mm (5.5 in)
Capacity per fork leg approx. 500 ccm
Fork oil SAE 5
STANDARD ADJUSTMENT - FORK
125 EXE 125 Supermoto
Frame Central chrome-moly-steel frame
Fork White Power – Up Side Down 40 TA
Wheel travel front/rear 220/260 mm (8,7/10,2 in)
Rear suspension WP Progressive Damping System shock absorber, aluminium swingarm
Front brake Disc brake with carbon-steel brake disc, brake caliper floated
Front brake disc Ø 260 mm (10,2 in) Ø 320 mm (12,6 in)
Rear brake Disc brake with carbon-steel brake disc Ø 220 mm (8.7 in), brake caliper floated
Brake discs Wear limit max. 0,4 mm (0,016 in)
Front tires 3.00 - 21“ 110/70 - 17“
Air pressure, driver only 1,8 bar (26 psi) 1,8 bar (26 psi)
Air pressure, driver plus passenger
2,0 bar (29 psi) 2,0 bar (29 psi)
Rear tires 4.60 - 18“ 130/70 - 17“
Air pressure, driver only 2,0 bar (29 psi) 2,1 bar (30 psi)
Air pressure, driver plus passenger
2,2 bar (32 psi) 2,3 bar
(33 psi)
Fuel tank capacity 11,0 liter (3 US gallons), 2,5 liter (0,6 US gallons) reserve
Final drive ratio 14:40 t 14:38 t
Chain O-ring 5/8 x 1/4 "
Battery
maintenance free 12V 3Ah
Lamps head light H4 12V 60/55W (socket P43t)
parking light 12V 5W (socket W2,1x9,5d)
cockpit light 12V 2W (socket W2x4,6d)
stop and tail light 12V 21/5W (socket BaY15d)
flasher 12V 10W (socket Ba15s)
Steering head angle 63°
Wheel base 1461 ± 10 mm (57,5 ± 0,4 in)
S eat height, unloaded 865 mm (34,0 in) 830 mm (32,7 in)
Ground clearance, unloaded 290 mm (11,4 in) 255 mm (10,0 in)
Dead-weight
* 104 kg (230 lbs)
Max. permissible front axle load 145 kg (320 Ibs)
Max. permissible rear axle load 190 kg (419 Ibs)
Max. permissible laden weight 335 kg (740 Ibs)
TECHNICAL SPECIFICATIONS CHASSIS 125 EXE / 125 SUPERMOTO 2000
