TECHNICAL SPECIFICATIONS - CHASSIS 400 / 620 R/XC e ‘98
Frame Central chrome-moly-steel frame
Fork WP-Up Side Down Topadjuster 4054 IBS
Wheel travel front/rear 300 / 320 mm (11,8 / 12,6 in)
Rear suspension Central shock absorber WP IBS with PRO-LEVER linkage to rear- swing-arm with needle bearing
Front brake Disc brake with carbon-steel brake disc 300 mm (11,8 in), brake caliper floated
Rear brake Disc brake with carbon-steel brake disc 220 mm (8,7 in), brake caliper floated
Tyres front 90/90 - 21 54R
Air press. road, driver only
1,5 bar (22 psi)
Air press. road with passenger
2,0 bar (29 psi)
Tyres rear 140/80 - 18 70R
Air press. road, driver only
2,0 bar (29 psi)
Air press. road with passenger
2,2 bar (31 psi)
Fuel tank capacity 11,3 liter (3 US gallons) or 20 liter (5,3 US gallons), 1,5 liter (0,4 US gallons) reserve
Final drive ratio 400 R/XC e 16:45t
620 R/XC e 16:40t
Chain O – Ring
5
/8 x
1
/4"
Battery maintenance-free battery 12V 8Ah
Steering angle 62,5 °
Wheel base 1510 ± 10 mm (59,4 ± 0,4 in)
Seat high 940 mm (37 in)
Ground clearance 350 mm (13,8 in)
Dead weight without fuel
400: 137kg (302,4 lbs)
Max. permissible front axle load
151 kg (333 lbs)
Max. permissible rear axle load
297 kg (656 lbs)
Max. permissible laden weight
350 kg (773 lbs)
K4T96S
Compression adjuster 3
Rebound adjuster 4
Spring 66/260
Spring preload 23 mm (0,9 in)
STANDARD-ADJUSTMENT - SHOCK ABSORBER
K4T96L3
Compression adjuster 10
Rebound adjuster 14
Spring 4,4 N/mm
Spring preload 10 mm (0,4 in)
Air chamber length 130 mm (5 in)
Capacity per fork leg ca 500 cc
Fork oil SAE5
STANDARD ADJUSTMENT - FORK
Collar screw front axle M 10 40 Nm (30 ft.lb)
Collar nut rear axle M 20x1,5 80 Nm (59 ft.lb)
Hex. nut swing arm bolt M 14x1,5 100 Nm (74 ft.lb)
Clamping screw upper fork bridge M 8 20 Nm (15 ft.lb)
Clamping screw lower fork bridge M 8 15 Nm (11 ft.lb)
Clamping screws fork stubs M 7 7 Nm (5 ft.lb)
Other screws chassis M6 10 Nm (7 ft.lb)
M8 30 Nm (22 ft.lb)
M10 50 Nm (37 ft.lb)
TORQUES
