13 BRAKE SYSTEM 103
The ABS warning lamp
must light up briefly after the ignition is switched on and should
then go out after starting off. If it does not go out after starting off or if it lights up while
riding, this indicates a fault in the ABS system. In this case, the ABS is no longer enabled
and the wheels may lock during braking. The brake system itself stays functional; only ABS
control is not available.
The ABS warning lamp may also light up if the rotating speeds of the front and rear wheels
differ greatly under extreme riding conditions, for example when making wheelies or if the
rear wheel spins. This causes the ABS to switch off.
To reenable the ABS, the vehicle must be stopped and the ignition switched off. The ABS
is reenabled when the vehicle is switched on again. The ABS warning lamp goes out when
you start off.
Button
can be used to switch ABS off manually (see Starting).
13.2 Checking the brake discs
Warning
Danger of accidents Reduced braking efficiency due to worn brake disc(s).
– Change the worn brake disc(s) without delay. (Your authorized KTM workshop will be glad to help.)
400480-10
– Check the thickness of the front and rear brake discs at several places on the disk to
see if it conforms to measurement
.
Info
Wear reduces the thickness of the brake disc in area
of the brake disc.
Brake discs - wear limit
Front 4.5 mm (0.177 in)
Rear 3.6 mm (0.142 in)
» If the brake disc thickness is less than the specified value:
