5 SERIAL NUMBERS 21

5.3 Engine number

401949-10

The engine number



is stamped on the left side of the engine under the engine sprocket.

5.4 Key number

402245-10

The key number



can be found on the KEYCODECARD.

Info

You need the key number to order a spare key. Keep the KEYCODECARD in a safe

place.
