4.1 Chassis tightening torques
Remaining screws, chassis EJOT PT
®
K60x25‑Z 2 Nm (1.5 lbf ft)
Screw, intake air temperature sen-
sor
0.7 Nm (0.52 lbf ft)
Screw, oil fill level sensor G 3/4 " 7 Nm (5.2 lbf ft)
Screw, pressure regulator EJOT PT
®
K60x25‑Z 2.3 Nm (1.7 lbf ft)
Screw, seat fixing EJOTEJOFORM PT
®
K60x23/18 2.5 Nm (1.84 lbf ft)
Screw, emergency OFF switch (All
EXC models)
M4 0.7 Nm (0.52 lbf ft)
Screw, fixed grip M4 5 Nm (3.7 lbf ft)
Loctite
®
243™
Spoke nipple, front wheel M4.5 6 Nm (4.4 lbf ft)
Spoke nipple, rear wheel M4.5 6 Nm (4.4 lbf ft)
Remaining nuts, chassis M5 5 Nm (3.7 lbf ft)
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
Screw, battery terminal M5 2.5 Nm (1.84 lbf ft)
Screw, ground wire in tail section M5 5 Nm (3.7 lbf ft)
Screw, light switch (All EXC mod-
els)
M5 1 Nm (0.7 lbf ft)
Screw, shock absorber adjusting
ring
M5 5 Nm (3.7 lbf ft)
Screw, turn signal switch (All EXC
models)
M5 1 Nm (0.7 lbf ft)
Nut, cable on starter motor M6 4 Nm (3 lbf ft)
Remaining nuts, chassis M6 10 Nm (7.4 lbf ft)
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
Screw, ball joint of push rod on
foot brake cylinder
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, chain sliding guard M6 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, front brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, manifold on silent block M6 6 Nm (4.4 lbf ft)
Screw, oil pump holder on oil tank M6 6 Nm (4.4 lbf ft)
Screw, rear brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, silent block on frame M6 6 Nm (4.4 lbf ft)
Screw, throttle grip M6 5 Nm (3.7 lbf ft)
Fuel connection on fuel pump M8 10 Nm (7.4 lbf ft)
Nut, foot brake lever M8 15 Nm (11.1 lbf ft)
Nut, foot brake lever stop M8 20 Nm (14.8 lbf ft)
Nut, pull switch (All XC‑W models) M8 0.4 Nm (0.3 lbf ft)
Nut, rear sprocket screw M8 35 Nm (25.8 lbf ft)
Loctite
®
2701™
Nut, rim lock M8 12 Nm (8.9 lbf ft)
Remaining nuts, chassis M8 25 Nm (18.4 lbf ft)
Remaining screws, chassis M8 25 Nm (18.4 lbf ft)
