TECHNICAL DATA 22
137
Screw, ball joint of push rod on
foot brake cylinder
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, battery support bracket M6 6 Nm (4.4 lbf ft)
Screw, brake line guide on link
fork
M6 6 Nm (4.4 lbf ft)
Screw, chain guide on link fork at
the front
M6x45 10 Nm (7.4 lbf ft)
Screw, chain guide on link fork at
the rear
M6x16 10 Nm (7.4 lbf ft)
Screw, chain sliding guard on link
fork
M6 6 Nm (4.4 lbf ft)
Screw, connector board with com-
bination instrument
M6 5 Nm (3.7 lbf ft)
Screw, front brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, fuel tank spoiler on radiator M6 6 Nm (4.4 lbf ft)
Screw, ground wire on frame M6 10 Nm (7.4 lbf ft)
Screw, hand lever M6 5 Nm (3.7 lbf ft)
Screw, rear brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, seat fixing M6 8 Nm (5.9 lbf ft)
Screw, starter cable to starter relay M6 6 Nm (4.4 lbf ft)
Screw, throttle grip M6 5 Nm (3.7 lbf ft)
Nut, foot brake lever stop M8 20 Nm (14.8 lbf ft)
Nut, rear sprocket screw M8 35 Nm (25.8 lbf ft)
Loctite
®
2701™
Nut, rim lock M8 12 Nm (8.9 lbf ft)
Remaining nuts, chassis M8 25 Nm (18.4 lbf ft)
Remaining screws, chassis M8 25 Nm (18.4 lbf ft)
Screw, bottom triple clamp M8 12 Nm (8.9 lbf ft)
Screw, chain sliding piece M8 15 Nm (11.1 lbf ft)
Screw, engine sprocket cover M8 15 Nm (11.1 lbf ft)
Screw, fork stub M8 15 Nm (11.1 lbf ft)
Screw, front brake caliper M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, handlebar clamp M8 20 Nm (14.8 lbf ft)
Screw, manifold on cylinder head
brace
M8 15 Nm (11.1 lbf ft)
Screw, side stand attachment
(XC‑F US)
M8 33 Nm (24.3 lbf ft)
Loctite
®
2701™
Screw, subframe bottom M8 30 Nm (22.1 lbf ft)
Loctite
®
2701™
Screw, subframe top M8 35 Nm (25.8 lbf ft)
Loctite
®
2701™
Screw, top steering stem M8 20 Nm (14.8 lbf ft)
Loctite
®
243™
Screw, top triple clamp M8 17 Nm (12.5 lbf ft)
Engine carrying screw M10 60 Nm (44.3 lbf ft)
Remaining nuts, chassis M10 45 Nm (33.2 lbf ft)
