KTM 250 SX-F 2023 User Manual

28 LIST OF SYMBOLS
146
28.1 Yellow and orange symbols
Yellow and orange symbols indicate an error condition that requires prompt intervention. Active driving aids are
also represented by yellow or orange symbols.
Malfunction indicator lamp lights up/flashes orange – The OBD has detected a malfunction
in the vehicle electronics. The malfunction indicator lamp also lights up if traction control is
activated and the speed limiter intervenes.
TC indicator lamp lights up orange – TC is enabled or is currently intervening. The TC indica-
tor lamp flashes if launch control is activated.
28.2 Green and blue symbols
Green and blue symbols reflect information.
QS indicator lamp lights up blue – The quickshifter is activated. The QS indicator lamp
flashes when the quickshifter is being programmed.
Indicator lamp
B
lights up green – ADVANCED mapping is activated.
28.3 White symbols
White symbols convey information.
Indicator lamp
A
lights up white – STANDARD mapping is activated.

KTM 250 SX-F 2023 Specifications

General

Engine Type	1-cylinder, 4-stroke engine
Bore x Stroke	78 mm x 52.3 mm
Compression Ratio	14.4:1
Starter	Electric starter
Transmission	5-speed
Fuel System	Keihin EFI, throttle body 44 mm
Cooling	Liquid cooled
Ignition	Keihin EMS
Front Suspension	WP XACT-USD, Ø 48 mm
Rear Suspension	WP XACT Monoshock with linkage
Front Brake	Disc brake
Rear Brake	Disc brake
Front Tire	80/100-21
Ground Clearance	370 mm
Displacement	249.9 cm³
Final Drive	Chain
Frame	Central double-cradle type 25CrMo4 steel
Rear Tire	100/90-19
Front Wheel	1.60 x 21
Rear Wheel	2.15 x 19
Wheelbase	1, 485 mm ± 10 mm
