KTM 690 SMC R 2014 User Manual

20 TROUBLESHOOTING 160
Faults Possible cause Action
Turn signal, brake light and horn not
functioning
Fuse 5 blown – Change the fuses of individual power consumers.
( p. 121)
Time is not (correctly) displayed Fuse 1 blown – Change the fuses of individual power consumers.
( p. 121)
– Set the clock. ( p. 32)
Battery discharged Ignition not switched off when vehicle
was parked
–
Recharge the battery. x ( p. 115)
Battery is not charged by alternator –
Check the charging voltage. x
–
Check the quiescent current. x
Combination instrument shows nothing
in the display
Fuse 1 or 2 blown – Change the fuses of individual power consumers.
( p. 121)
– Set the clock. ( p. 32)
Speedometer in combination instru-
ment not functioning
Speedometer wiring harness is dam-
aged or plug-in connection is oxidized
– Check the wiring harness and plug-in connection.
