22 TECHNICAL DATA 180
Screw, side stand M10 35 Nm (25.8 lbf ft) Loctite
®
243™
Screw, top shock absorber M10 45 Nm (33.2 lbf ft) Loctite
®
243™
Banjo bolt, brake line M10x1 20 Nm (14.8 lbf ft) –
Screw, front brake caliper M10x1.25 45 Nm (33.2 lbf ft) Loctite
®
243™
Screw, swingarm pivot M12 80 Nm (59 lbf ft) –
Lambda sensor M12x1.25 25 Nm (18.4 lbf ft) Copper paste
Nut, linkage lever on swingarm M14x1.5 100 Nm (73.8 lbf ft) –
Nut, linkage lever to rocker arm M14x1.5 100 Nm (73.8 lbf ft) –
Screw, bottom steering head M20x1.5 60 Nm (44.3 lbf ft) Loctite
®
243™
Screw, top steering head M20x1.5 12 Nm (8.9 lbf ft) –
Screw, front wheel spindle M24x1.5 45 Nm (33.2 lbf ft) –
Nut, rear wheel spindle M25x1.5 90 Nm (66.4 lbf ft) –
