4 TECHNICAL DATA
22
Screw, front brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, ignition lock M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, license plate holder, bot-
tom
M6 8 Nm (5.9 lbf ft)
Screw, license plate holder, top M6 8 Nm (5.9 lbf ft)
Screw, magnetic holder on side
stand
M6 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, main silencer clamp M6 10 Nm (7.4 lbf ft)
Copper paste
Screw, radiator bleeding M6 8 Nm (5.9 lbf ft)
Screw, radiator bracket, bottom M6 8 Nm (5.9 lbf ft)
Screw, radiator bracket, top M6 10 Nm (7.4 lbf ft)
Screw, rear brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, right side cover M6x12 5 Nm (3.7 lbf ft)
Screw, SAS valve M6 4 Nm (3 lbf ft)
Screw, seat lock M6 5 Nm (3.7 lbf ft)
Screw, upper part of the air filter
box
M6 2 Nm (1.5 lbf ft)
Screw, voltage regulator M6 8 Nm (5.9 lbf ft)
Screw, wheel speed sensor M6 6 Nm (4.4 lbf ft)
Handle bar end screw M8 15 Nm (11.1 lbf ft)
Nut, rear sprocket screw M8 35 Nm (25.8 lbf ft)
Loctite
®
2701™
Remaining nuts, chassis M8 25 Nm (18.4 lbf ft)
Remaining screws, chassis M8 25 Nm (18.4 lbf ft)
Screw, bottom triple clamp M8 12 Nm (8.9 lbf ft)
Screw, chain sliding piece M8 15 Nm (11.1 lbf ft)
Screw, connection lever on frame M8 30 Nm (22.1 lbf ft)
Loctite
®
243™
Screw, foot brake lever M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, fork stub M8 15 Nm (11.1 lbf ft)
Screw, front footrest bracket M8 25 Nm (18.4 lbf ft)
Screw, fuel tank bracket M8 15 Nm (11.1 lbf ft)
Screw, fuel tank, bottom M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, fuel tank, top M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, grab handle M8 10 Nm (7.4 lbf ft)
Screw, handlebar clamp M8 20 Nm (14.8 lbf ft)
Screw, heel protector M8x12 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, main silencer holder M8 25 Nm (18.4 lbf ft)
Screw, main silencer holder on
fuel tank
M8 25 Nm (18.4 lbf ft)
