TECHNICAL DATA 4
19
4.1 Chassis tightening torques
Brake fluid reservoir cover, front - 0.7 Nm (0.52 lbf ft)
Radiator hose hose clamp - 2.2 Nm (1.62 lbf ft)
Remaining screws, chassis EJOTPT
®
K45x12 1 Nm (0.7 lbf ft)
Remaining screws, chassis EJOTPT
®
K50x12 1 Nm (0.7 lbf ft)
Remaining screws, chassis EJOTPT
®
K50x14 1 Nm (0.7 lbf ft)
Remaining screws, chassis EJOTPT
®
K50x16 2 Nm (1.5 lbf ft)
Remaining screws, chassis EJOTPT
®
K50x18 2 Nm (1.5 lbf ft)
Screw, headlight EJOTPT
®
K50x14 3 Nm (2.2 lbf ft)
Throttle valve body hose clamp - 2.8 Nm (2.07 lbf ft)
Remaining nuts, chassis M4 3 Nm (2.2 lbf ft)
Remaining screws, chassis M4 3 Nm (2.2 lbf ft)
Screw, fixed grip, left M4 3 Nm (2.2 lbf ft)
Remaining nuts, chassis M5 5 Nm (3.7 lbf ft)
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
Screw, air filter box M5 3 Nm (2.2 lbf ft)
Screw, brake fluid reservoir for rear
brake
M5 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, combination instrument M5 4 Nm (3 lbf ft)
Screw, combination switch, left M5 2 Nm (1.5 lbf ft)
Screw, combination switch, right M5 5 Nm (3.7 lbf ft)
Screw, engine sprocket cover M5 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, fuel level sensor M5 3 Nm (2.2 lbf ft)
Screw, fuel tank cover M5 3 Nm (2.2 lbf ft)
Screw, headlight mask M5 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, heat guard M5 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, license plate holder M5 3 Nm (2.2 lbf ft)
Screw, lower rear panel M5 3 Nm (2.2 lbf ft)
Screw, mask support M5 3 Nm (2.2 lbf ft)
Screw, side stand sensor M5 2 Nm (1.5 lbf ft)
Loctite
®
243™
Screw, support roller M5 4 Nm (3 lbf ft)
Loctite
®
243™
Screw, throttle grip M5 3.5 Nm (2.58 lbf ft)
Screw, trim M5 3 Nm (2.2 lbf ft)
Nut, cable on starter motor M6 5 Nm (3.7 lbf ft)
Nut, hand brake lever M6 5 Nm (3.7 lbf ft)
Nut, push rod, foot brake lever M6 6 Nm (4.4 lbf ft)
Nut, shift rod M6 6 Nm (4.4 lbf ft)
Nut, shift rod M6LH 6 Nm (4.4 lbf ft)
Remaining nuts, chassis M6 10 Nm (7.4 lbf ft)
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
