KTM 890 DUKE R 2022 User Manual

1 MEANS OF REPRESENTATION
2
1.1 Symbols used
The meaning of specific symbols is described below.
Indicates an expected reaction (e.g. of a work step or a function).
Indicates an unexpected reaction (e.g. of a work step or a function).
Indicates a page reference (more information is provided on the specified page).
Indicates information with more details or tips.
Indicates the result of a testing step.
Indicates a voltage measurement.
Indicates a current measurement.
Indicates a resistance measurement.
Indicates the end of an activity including potential rework.
1.2 Formats used
The typographical formats used in this document are explained below.
Proprietary name Indicates a proprietary name.
Name
®
Indicates a protected name.
Brand™ Indicates a brand available on the open market.
Underlined terms Refer to technical details of the vehicle or indicate technical terms, which
are explained in the glossary.

KTM 890 DUKE R 2022 Specifications

General

Engine Type	2-cylinder, 4-stroke, parallel twin
Displacement	889 cm³
Transmission	6-speed
Cooling	Liquid cooled
Seat Height	834 mm
Weight (without fuel)	166 kg
Front Suspension	WP APEX 43
Front Tire	120/70 ZR 17
Rear Tire	180/55 ZR 17
Bore x Stroke	90.7 mm x 68.8 mm
Compression Ratio	13.5:1
Fuel System	Electronic Fuel Injection
Final Drive	Chain
Power	121 hp
Torque	99 Nm
Fuel Tank Capacity	14 liters
Rear Suspension	WP APEX
Rear Brake	240 mm disc, single-piston floating caliper
ABS	Bosch 9.1 MP (incl. Cornering-ABS and Supermoto mode)
Frame	Chromoly-steel trellis frame, powder coated
Front Brake	2 x Brembo Stylema four piston, radially mounted calipers
Wheelbase	1, 482 mm
