ENGLISH
5
SERIAL NUMBER LOCATIONS »
Chassis number
The chassis number is located on the right side of the steering head tube and
on the type label. Write this number into the relevant area on page 1.
Engine number, engine type
The engine number and engine type are embossed in the engine case near
the shift lever. Write this number into the relevant area on page 1.
Clutch lever
The clutch lever [1] is located on the left side of the handlebar. The adjust-
ing screw [A] is used to change the original position of the clutch lever (see
maintenance work on chassis and engine).
The clutch is hydraulically actuated and adjusts itself automatically.
Choke lever
If the choke lever [2] is pulled backwards, a bore in the carburetors will be
opened in the carburetor through which the engine may draw in additional
fuel. This produces a „rich“ fuel/air mixture necessary for cold start. The fuel
quantity and thus the engine speed are determined by the choke lever posi-
tion.
At temperatures over 5°C (41°F) it will suffice to pull the choke lever half way
out. At temperatures below 5°C (41°F) the choke lever should be pulled all
the way out. The hole is closed again by pushing the choke lever all the way
back in.
Hand brake lever
The hand brake lever [3] is mounted on the handlebars on the right and actu-
ates the front wheel brake. The adjusting screw [B] can be used to change
the basic position of the hand brake lever (see "Maintenance").
OPERATION INSTRUMENTS »
1
2
3
B
A
