Ignition lock
The ignition lock has 3 switching positions.
Ignition off, (engine can't be started)
Ignition on, (engine can be started)
Ignition off, handlebar blocked
To switch the ignition to position turn the ignition key to position and firmly press it
into the lock. Turn the handlebar to the left, then turn the ignition key to the left.
The ignition key can be withdrawn in position and .
Combination switch
The rocker switch LIGHTS [1] actuates the high beam or low beam.
High-beam light
Low-beam light
The light signal (high beam) is actuated with button [2].
The indicator switch [3] returns to central position after actuation. Press flasher
switch towards switch housing to switch off the flasher.
The horn is sounded with button [4].
OPERATION INSTRUMENTS »
14
2
1
1
3
4
