Starter tip switch, Emergency OFF tip switch
The emergency off switch [1] is provided for emergency situations and should not be used
to switch off the engine.
The engine is ready for operation in position (ignition circuit and starter circuit are switched
on).
The engine cannot be started in position (ignition circuit and starter circuit are inter-
rupted).
Use the starter tip switch [3] to operate the electric starter.
Filler cap
The filler cap [4] can be locked. It is equipped with a tank ventilation system.
To open, insert the ignition key, turn 45° in a clockwise direction and tilt the filler cap back.
After refueling, pull out the ignition key and press down on the filler cap until the lock engages.
OPERATION INSTRUMENTS »
15
4
1
3
