3SPECIFICATIONS
SPECIFICATIONS
SPECIFICATION TABLE
Model BX1870D BX2370D BX2670D
PTO power *1 kW (HP) 10.2 (13.7) 13.2 (17.7) 14.5 (19.5)
Engine
Maker KUBOTA
Model D722 D902 D1005
Type Indirect injection, vertical, water-cooled, 4-cycle diesel
Number of cylinders 3
Bore and stroke mm (in.) 67x68 (2.64x2.68) 72x73.6 (2.83x2.90) 76x73.6 (2.99x2.90)
Total displacement cm (cu. in.) 719 (43.9) 898 (54.8) 1001 (61.1)
Engine gross power *2 kW 13.4 (18.0) 17.1 (23.0) 19.0 (25.5)
Rated revolution rpm 3200
Low idling revolution rpm 1350 to 1550
Maximum torque N-m (lbf-ft) 44.9 (33.1) 56.1 (41.4) 60.2 (44.4)
Battery
12V, RC: 55min,
CCA:450A
12V, RC:80min, CCA:540A
Fuel Diesel fuel No.2 [above -10 (14 )] Diesel fuel No.1 [below -10 (14 )]
Capacities
Fuel tank L (U.S.gals.) 25 (6.6)
Engine crankcase (with filter) L (U.S.qts.) 2.9 (3.06) 3.1 (3.3) 3.5 (3.7)
Engine coolant L (U.S.qts.) 2.5 (2.6) 2.7 (2.8) 2.9 (3.1)
Recovery tank L (U.S.qts.) 0.4 (0.4)
Transmission case L (U.S.gals.) 11.6 (3.1)
Dimensions
Overall length (without 3p) mm (in.) 2035 (80.1) 2120 (83.5)
Overall length (with 3p) mm (in.) 2340 (92.1) 2425 (95.5)
Overall width (min. tread) mm (in.) 1145 (45.1)
Overall height
(with ROPS) mm (in.) 2190 (86.2) 2215 (87.2)
mm (in.) 1230 (48.4) (Top of seat) 1255 (49.4) (Top of seat) 1330 (52.4) (Top of seat)
Wheel base mm (in.) 1340 (52.8) 1400 (55.1)
Min. ground clearance mm (in.) 150 (5.9) 175 (6.9)
Tread
Front mm (in.) 880 (34.6) 930 (36.6)
Rear mm (in.) 820 (32.2)
Weight (with ROPS) kg (lbs.) 610 (1345) 640 (1410) 665 (1466)
Clutch N / A
Traveling
system
Tire
Front 16x7.50-8 18x8.50-10
Rear 24x12.00-12 26x12.00-12
Steering Hydrostatic type power steering
Transmission Main: Hydrostatic transmission, High-Low gear shift (2 forward, 2 reverse)
Brake Wet disk type
Min. turning radius m (feet) 2.18 (7.15) 2.3 (7.5)
