Kubota BX2380 Instruction Manual

10
25. Reinstall inside dash panel using the seven (7)
thumbscrews from step 1.
Inside dash panel and thumbnuts
26. Reinstall front window latches using the hardware
saved from step 2.
Latch bolts
Unit Maintenance
• Regularly clean air filters located on each end of
the heater assembly
• Clean dirt and dust from filters by lightly tapping
filter
• The filters can also be cleaned by rinsing with cool
water
NOTE: Never use alcohol or ammonia based cleaners
on plastic surfaces. Clean only using water and mild
soap.

Kubota BX2380 Specifications

General

Engine Model	D902
Displacement	54.8 cu in (0.9 L)
Engine Power	23 hp (17.2 kW)
PTO Power	17.7 hp (13.2 kW)
Transmission	Hydrostatic
Drive	4WD
Fuel Capacity	6.6 gal (25 L)
Hydraulic System	Open center
3-Point Hitch	Category I
Lift Capacity at 24"	680 lbs (308 kg)
Tire Size (Front)	18x8.5-10
Tire Size (Rear)	26x12-12
Engine Type	3-cylinder diesel
Wheelbase	55.1 in (1400 mm)
Weight	1433 lbs (650 kg)
