4
NOTE:
• Check the contents as shown in the parts list
 PARTS LIST
Ref. No.
Part Name
Q’TY
REMARKS
1
Hose Clamps 5/8’’
4
27-0048
2
Fitting – 3/8’’NPT x 5/8’’ Hose nipple
1
27-0097
3
Heater Hose 5/8” – Inlet
45 inch
27-0225
4
Heater Hose 5/5’’ – Outlet
35 inch
27-0225
5
Hose Clamps – 1.25’’
2
27-2687
6
Grommet
1
28-0083
7
Heater Hose Insulation – Inlet
45 inch
28-0858
8
Heater Hose Insulation – Outlet
20 inch
28-0858
9
Heater Hose Insulation – Outlet
15 inch
28-0858
10
Tie Wrap – 11’’ Black
15
28-0382
11
Heater Assembly
1
T12-13203
12
Jumper Wire Harness
1
T19-0983
13
Thermostat Spacer
1
T27-6144
14
Thermostat Gasket
2
T27-6145
15
Hex Head Bolts M8x1.25x60mm
2
T29-2046
16
Tee Fitting 1’’x1’’x5/8’’
1
T37-0104
17
Installation Instructions
1
T66-0060

Kubota BX2380 Specifications

General

Engine Model	D902
Displacement	54.8 cu in (0.9 L)
Engine Power	23 hp (17.2 kW)
PTO Power	17.7 hp (13.2 kW)
Transmission	Hydrostatic
Drive	4WD
Fuel Capacity	6.6 gal (25 L)
Hydraulic System	Open center
3-Point Hitch	Category I
Lift Capacity at 24"	680 lbs (308 kg)
Tire Size (Front)	18x8.5-10
Tire Size (Rear)	26x12-12
Engine Type	3-cylinder diesel
Wheelbase	55.1 in (1400 mm)
Weight	1433 lbs (650 kg)
