2. Rear wheels
IMPORTANT :
• Do not the turn rear discs to obtain wider tread.
• Always attach tires as shown in the figures in the following table.
If you not attach the rear wheel as illustrated in the table, transmission parts may be damaged.
You can not adjust width of the rear tread.
Models BX1880 BX2380 and BX2680
Tire 24x12.00-12 Turf, 24x12.00-12 Bar 26x12.00-12 Turf, 26x12.00-12 Bar, 26x12.00-12 Ind.
Tread
(A) 820 mm
(32.2 in.)
(B) 820 mm
(32.2 in.)
How to jack up rear part of the tractor
WARNING
To avoid serious injury or death:
• Before jacking up the tractor, park it on a firm and level ground and chock the front wheels.
• Fix the front axle to keep it from pivoting.
• Select jacks that withstand the machine weight and set them up as shown in the following figure.
(1) Frame (2) Jack point
TIRES, WHEELS, AND BALLAST WHEEL TREAD
66
BX1880, BX2380, BX2680

Kubota BX2680 Specifications

General

Engine Type	Diesel
Engine Model	Kubota D1005
Engine Power	25.5 HP
Transmission Type	Hydrostatic
Drive	4WD
Front Axle	Bevel gear
Steering	Power Steering
Brakes	Wet disc
Hydraulic System Type	Open center
Hydraulic Pump Capacity	6.2 GPM
3-Point Hitch	Category I
3-Point Hitch Lift Capacity at 24 inches	680 lbs
Fuel Capacity	6.6 gallons
Wheelbase	55.1 inches
Length	95.5 inches
PTO Power	19.5 HP
Number of Gears	3-range
Tire Size (Front)	18x8.5-10
Tire Size (Rear)	26x12-12
