(1) Battery (2) Clamp
IMPORTANT :
• Since the metal-battery-holder can crack, do not
tighten it too much.
• To slow charge the battery, connect the battery
positive terminal to the charger positive terminal
and the negative to the negative, then charge as
follows.
Charging the battery For at least 1 hour at 6.5 amperes
• A boost charge is only for emergencies. It will
partially charge the battery at a high rate and in a
short time. When using a boost-charged battery, it
is necessary to recharge the battery as early as
possible.
Failure to do this will shorten the battery's service
life.
• When the specific gravity of electrolyte is shown in
the following table, the charging is completed.
Specific gravity of electrolyte Between 1.27 and 1.29
1.2 Dealing with the battery when storing
the tractor for a long period
1. Remove the battery from the tractor.
2. Adjust the electrolyte to the proper level.
3. Store the battery in a dry place out of direct
sunlight.
The battery self-discharges while it is stored.
Recharge the battery once every three months in hot
seasons and once every six months in cold seasons.
2. Cleaning the air cleaner element
WARNING
To avoid serious injury or death:
• Be sure to stop the engine and remove the key
before cleaning the air cleaner element.
IMPORTANT :
• The air cleaner uses a dry element. Never apply
oil to the air cleaner.
• Do not run the engine with filter element
removed.
• Align the arrow marks when reinstalling the
cover. If the cover is improperly fitted, dust
passes by the baffle and directly adheres to the
air cleaner element.
NOTE :
• Check to see if the evacuator valve is blocked
with dust.
1. Remove the air cleaner cover and the element.
a. Undo the hook.
b. Turn the air cleaner cover clockwise and detach
it.
2. Clean the air cleaner element.
When dry dust adheres to the element, blow
compressed air from the inside, turning the
element. Pressure of compressed air must be the
value shown in the following table.
Pressure of compressed air Below 205 kPa (2.1 kgf/cm
2
, 30 psi)
3. When carbon or oil adheres to the element, follow
the following procedure.
a. Soak the air cleaner element in detergent for
the following minutes.
Soaking the air cleaner element in detergent For 15 minutes
b. Then wash it several times in water.
c. Rinse the air cleaner element with clean water.
d. Dry the air cleaner element naturally.
e. After the air cleaner element is fully dried,
inspect inside of it with a light and check if it is
damaged or not.
Refer to the instructions on the label attached to
the case.
SERVICE EVERY 100 HOURS PERIODIC SERVICE
