CNC:
Index Service Part # File Name
Description
Qty
1 KUGF1800-ASM-030 1
2 A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD 2
3 A00-0023 FLANGE_BOLT_1-4X3-4 Flange Bolt, 1/4" x 3/4", YD 4
4 A00-0059 FLANGE-NUT-5-16 Flange Nut, 5/16", YD 2
5 A00-0061 TEKT-0021 Striker Mounting Plate 2
6 A00-0084 TEKT-0070 Gas Shock 2
7 A00-0085 TEKT-0069 Gas Shock Stud 2
8 A00-0101 STRIKER-PIN Striker Pin 2
9 A00-0103 HEX-NUT-M12X1 Hex Nut, M12 x 1.0, YD 2
10 A00-0131 TEKT-0181 External Fuel Cap 1
11 A00-0141 ROUND_MIRROR_6_INCH External 6" Mirror 2
12 A00-0179 FLANGE-NUT-1-2 1/2" Nut 2
13 A00-0202 TEKT-ASM-009R Right Mirror Bracket Weldment 1
14 A00-0203 TEKT-ASM-009 Left Mirror Bracket Weldment 1
15 A00-0371 TEKT-0175 New LED Work Light (Blazer Intl) 4
16 A00-0389 KUBX2380-NOSTRIL Plastic Light Nostril 2
Accessories Assembly
Daryl Furkalo
2017-06-28 Imp.
KUGF1800-ASM-035
B
SCALE 0.150
2
3
16
15
14
13
12
11
10
9
8
7
6
5
4
