Kubota L4701 User Manual

Run the engine at medium speed for a few
minutes to prevent damage to the transmission.
4. Replacing the fuel filter
1. Remove the fuel filter.
2. Put
a film
of clean fuel on the rubber seal of the
new filter.
3. Tighten the fuel filter quickly until it contacts the
mounting surface.
4. Tighten the fuel filter by hand an additional 1/2 turn
only.
(1) Fuel filter
5. Bleed the fuel system.
(See Bleeding the fuel system on page 125)
(1) Fuel shutoff-valve (A) Close
(B) Open
5. Cleaning the water separator
Do not
clean the water separator in the field, but in a
clean environment.
1. Close the fuel shutoff-valve.
2. Remove the retainer
ring, remove the cup, and
rinse the inside with kerosene.
(1) Fuel shutoff-valve
(2) Retainer ring
(3) Cup
(A)
Close
3. Remove
the
element
and dip it in the kerosene to
rinse.
(1) O ring
(2) Element
(3) Spring
(4)
Red float
(5) Cup
(6) Retainer ring
4. After
cleaning, reassemble the water separator,
keeping out dust and dirt.
5.
Bleed the fuel system.
(See Bleeding the fuel system
on page 125)
(1) Fuel shutoff-valve (A) Close
(B) Open
SERVICE EVER
Y 400 HOURS PERIODIC SERVICE
L4701
117

Kubota L4701 Specifications

General

Engine Type	Diesel
Cylinders	4
Brakes	Wet disc
Hydraulic System Type	Open center
3-Point Hitch	Category I
Engine Power	47 hp
Engine Power (Gross)	47.3 HP
PTO Horsepower	39.5 hp
Displacement	148.5 cu in
Fuel Capacity	11.6 gal (44 L)
Fuel Tank Capacity	11.6 gal (44 L)
Number of Gears	8 forward and 8 reverse
Hydraulic Pump Capacity	8.3 GPM
Height	91.7 inches (232 cm)
Tire Size (Front)	7-16
Tire Size (Rear)	14.9-24
Transmission	Gear Drive or HST (Hydrostatic)
