UNIVERSAL SYMBOLS
As a guide to the operation of your tractor, various universal symbols have been utilized on the instruments and
controls. The symbols are shown below with an indication of their meaning.
Safety Alert Symbol
Diesel Fuel
Fuel-Level
Engine-Rotational Speed
Hourmeter/Elapsed Operating Hours
Engine Coolant-Temperature
Diesel Preheat/Glow Plugs
(Low Temperature Start Aid)
Brake System
Clutch
Parking Brake
Engine Intake/Combustion Air-Filter
Battery Charging Condition
Engine Oil-Pressure
Turn Signal
Engine-Stop
Engine-Run
Starter Control
Power Take-Off Control-Off Position
Power Take-Off Control-On Position
Differential Lock
Position Control-Raised Position
Position Control-Lowered Position
Engine Warning
Emission Control
Draft Control-Shallow Position
Draft Control-Deep Position
3-Point Lowering Speed Control
Remote Cylinder-Retract
Remote Cylinder-Extend
Steering Wheel-Tilt Control
Hazard Warning Lights
Master Lighting Switch
Position Lamps
Headlight-Low Beam
Headlight-High Beam
Audible Warning Device
4-Wheel Drive-On
4-Wheel Drive-Off
Fast
Slow
Creep
Read Operator's Manual
Tractor-Forward Movement-Overhead View of
Machine
Tractor-Rearward Movement-Overhead View
of Machine
Engine Speed Control
Regeneration
DPF INHIBIT (Switch)
Parked Regeneration (Switch)
Parked Regeneration
Engine RPM Increase
