UNIVERSAL SYMBOLS
As a guide to the operation of your tractor, various universal symbols have been utilized on the instruments and
controls. The symbols are shown below with an indication of their meaning.
Safety Alert Symbol
Engine Warning
Diesel Fuel
Engine-Rotational Speed
Hourmeter/Elapsed
Operating Hours
Engine Coolant-
Temperature
Diesel Preheat/Glow
Plugs(Low Temperature
Start Aid)
Parking Brake
Engine Oil-Pressure
Turn Signal
Electrical Power-
accessories
Engine-Run
Engine-Start
Engine-Stop
Power Take-Off Clutch
Control-Off (Disengaged)
Position
Power Take-Off Clutch
Control-On (Engaged)
Position
Bi-Speed turn
Differential Lock, Front
Differential Lock, Rear
Auto-Mode
Position Control-Raised
Position
Position Control-Lowered
Position
3-Point Lifting / Lowering
Lift Arm Height
Draft Control
Remote Cylinder-Retract
Remote Cylinder-Extend
Remote Cylinder-Float
Hazard Warning Lights
Headlight-Low Beam
Headlight-High Beam
Four-Wheel Drive-On
Fast
Slow
Creep
Windshield Wiper
Windshield Wiper
Intermittent
Windshield Washer
Audible Warning Device
Lock
Rear Window Defroster
Steering Wheel-Tilt Control
Steering Wheel-Telescope
Control
Side Window Defroster
Empty
Full
PTO 540 rpm
PTO 1000 rpm
Engine Intake/Combustion
Air-Filter
Battery Charging Condition
Rev-limiter Control
Constant RPM Management
Front Suspension
Regeneration
Auto Regeneration (Switch)
Regeneration (Switch)
Parked Regeneration
Engine RPM Increase
Master System Warning
Beacon Light
