24
HANDLING THE SAFETY DEVICES
n Control lever lock
3
CAUTION
lWhen the excavator is not used
or left unattended, be sure to
place the lock lever in "Lock"
position.
The attachment control lever lock is located
on the left side.
(1) Pilot control lock lever (A) “Lock”
(B) “Unlock”
n Swing lock pin
This pin is used to lock the swing frame. Set
the lock pin to the “Lock” position and the
swing frame gets locked to the track frame.
IMPORTANT:
l Before locking the lock pin, be sure to
place the swing frame and the track
frame in parallel with each other.
(1) Swing lock pin (A) “Unlock”
(B) “Lock”

Kubota U17 Specifications

General

Width	990 mm
Bucket Digging Force	15.2 kN
Bucket Capacity	0.04 m³
Max Digging Depth	2310 mm
Max Reach	3900 mm
Transport Height	2340 mm
