19OPERATING THE MACHINE
ENGLISH
OPERATING FOLDABLE ROPS
To avoid serious injury or death:
A Always use the seat belt when the ROPS is
installed.
A Do not use the seat belt if a foldable ROPS is
down or there is no ROPS.
BTo Fold the ROPS
1. Loosen the knob bolts 1 to 2 turns.
2. Remove both lock pins.
3. Fold the ROPS.
To avoid personal injury:
A Hold the ROPS tightly with both hands and fold
the ROPS slowly and carefully.
4. Align lock pin holes and insert both lock pins and
secure them with the snap pins.
To avoid personal injury:
A Make sure that both lock pins are properly
installed and secured with the snap pins.
(1) Lock pin
(2) Snap pin
(3) Knob bolt
(1) ROPS
(1) Lock pin
(2) Snap pin
To Next Page
