Agility 16+ 50(45km/h ) SPECIFICATIONS
Dimensions
Overall length .............................. 2050 mm
Overall width................................. 735 mm
Overall height ................ 1210 mm/1270mm
Wheel base................................. 1340mm
Seat height .................................... 800 mm
Dry weight...................................... 120 kg
Capacities
Engine oil (exchange)..........................0.7 L
Transmission oil (exchange)................. 0.18
Fuel tank ............................................7.0 L
Maximum weight capacity ................ 278kg
Engine
Type ............ Four-stroke, air-cooled OHC
Displacement....................................50 cc
Bore and stroke......................39 X 41.4 mm
Compression ratio ............................10.5:1
Spark plug ................................. CR7HSA
Idle speed ................................. 2000 RPM
Cooling system ........................ Forced Air
Max Horsepower.................2.4kW/7000rpm
Max Torque........................3.5Nm/6000rpm
Starting system ......... Electric starter motor
Chassis
Tire size, front............................. 100/80–16
Tire size, rear............................. 120/80–14
Brake (front) ......................................DISC
Brake (rear) ......................................DRUM
Electrical
Ignition type ........................................ ECU
Battery ......................................... 12V 8Ah
Headlight .............................12V 55W/60W
Tail/brake light ..................12V 5W/12V 21W
Turn signal light .............................12V 10W
Position light.................................12V0.3W
Fuses .....................................15A*1, 10A*1
