MAINTENANCE
Clean your scooter regularly to protect
the surface finishes and inspect for
damage, wear, and oil, coolant or brake
fluid leakage.
Avoid cleaning products that are not
specifically designed for scooter, scooter,
or a u to m ob ile s urf ac e s. N o ns p ec ifi c
cleaners may contain harsh detergents
or chemical solvents that can damage the
metal, paint, and plastic on your scooter.
Cleaning
NOTE: If your scooter is still warm from recent
operation, give the engine and exhaust system
time to cool off before washing. Avoid the use of
high pressure water spray (typical in coin-operated
car washes), as the powerful spray can damage
components on your scooter.
Washing your scooter
1.Rinse the scooter thoroughly with cool
water to remove any loose dirt.
2. Clean the scooter with a sponge or soft
cloth using cool water. Avoid directing
water at muffler outlets and electrical
parts.
3. Clean the plastic parts using a cloth or
sponge dampened with a solution of mild
detergent and water. Rub the soiled
area gently, rinsing it frequently with fresh
water. Take care to keep brake fluid or
other chemical solvents away from the
scooter, as they will damage the plastic
and painted surface.
4. After cleaning, rinse the scooter
thoroughly with plenty of clean water.
This rinsing is required to remove
detergent residue which can corrode alloy
parts.
59

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the KYMCO AGILITY300 and is the answer not in the manual?

KYMCO AGILITY300 Specifications

Capacities IconCapacities
engine oil capacity (exchange)0.9 L
transmission oil capacity (exchange)0.18 L
fuel tank capacity13 L
maximum weight capacity341 kg
Engine Specifications IconEngine Specifications
engine typeFour-stroke, air-cooled OHC
engine displacement276 cc
bore and stroke72.7 X 66.4 mm
compression ratio10.6:1
max horsepower16.8 KW/7500 rpm
max torque23.5 Nm/6500 rpm
spark plugDPR6EA-9
idle speed1700±100 RPM
cooling systemCooling water
starting systemElectric starter motor
Chassis IconChassis
tire size, front110/70–16
tire size, rear140/70–14
brake, frontDISK(ABS)
brake, rearDISK(ABS)
Electrical IconElectrical
ignition typeECU
battery12v 10Ah
headlight12v/8w/6w
tail light12v 4w
brake light12v 6w
turn signal light12v 10w 2
license plate light12V 5w
position light12v 5w(F)12v 1w(B)
fuses30A 1, 25A 1, 15A 2, 10A*2
Weight and Dimensions IconWeight and Dimensions
overall length2200 mm
overall width765 mm
overall height1560 mm
wheel base1550 mm
seat height800 mm
curb weight191 kg
