15. ELECTRICAL EQUIPMENT
8
LIKE 50/125
IGNITION COIL INSPECTION
Continuity Test
Remove the met-in box. (
Ö
12)
Measure the resistance between the
ignition coil primary coil terminals.
Resistance (20℃): 0.153～0.187Ω
Measure the secondary coil resistance
between the spark plug cap and the primary
coil terminal as Figure A shown.
Resistance (20℃) (with plug cap):
10～14KΩ
Measure the secondary coil resistance
between the ignition coil terminal and the
primary coil terminal as Figure B shown.
Resistance (20℃) (without plug cap):
7～9KΩ
This test is to inspect the continuity of
ignition coil.
＊
Figure
A
Figure B
Ignition Coil

KYMCO Like 125 Specifications

General

Displacement	124.6 cc
Front Suspension	Telescopic Fork
Fuel System	Fuel Injection
Starting System	Electric
Transmission	CVT Automatic
Front Brake	Disc brake
Rear Brake	Drum brake
Bore x Stroke	52.4 mm x 57.8 mm
