KYMCO Mini LS User Manual

PRODUCT SPECIFICATIONS
Model Name EQ20CC(UK)
Maximum weight capacity
279 lbs (127kg)
Overall height
36.3in (921 mm)
Overall length
42.5 in (1080 mm)
Overall width
20.5 in (520mm)
Drive System
Rear-wheel drive, sealed
transaxle, 24-volt DC motor
Battery 12 V × 22 Ah × 2 Pcs
Battery charger
Off-board
Input voltage : 115/230VAC,
Output voltage : 24VDC
Output current : 4A
Front wheel Pneumatic, 9 in*2
Rear wheel Pneumatic, 9 in*2
Rear wheel drive system
Sealed transaxle drive with
differential
Braking system
Primary-motor
electromagnetic brake
Maximum incline angle
8 degree
Per-charge Run distance
Up to 13 miles (21km)
Maximum speed
Forward
4mph (6.6 kph)
Backward
2.1mph (3.3 kph)
Turning radius 43.7 in (1110 mm)
Overall height of seat
21.7 in (550 mm) (from
ground)
Overall width of seat 16.8 in (424 mm)
Overall depth of seat 13.8 in (350 mm)
Overall weight of seat 18.5 lbs (8.4 kg)
16
