1. GENERAL INFORMATION
1-19
ATV 150/125
CABLE & HARNESS ROUTING (MX’er 150/125)
Throttle Cable
Rear Brake Cable
Right Front Brake Cable
Handlebar Switch Lea
d
Front Brake Cable
Left Front Brake Cable
