KYMCO Xciting 500i User Manual

P.28/51
FUEL INJECTOR
REMOVAL
1. Disconnect the connector from the fuel injector.
2. Remove the bolt of the fuel injector.
3. Take out of the fuel pipe and fuel injector from the
Inlet pipe.
4. Remove the fuel injector from the fuel pipe
Connector Bolt
O-ring
Fuel Injector
Caution
Ensure the fuel pipe without any pressure, then remove
the fuel injector.
STEP 1 : Disconnect the fuel pump relay or fuel pump
connecter.
STEP 2: Turn the key to the ON position. Starting the
engine till the engine stop working.

KYMCO Xciting 500i Specifications

General

Fuel System	Electronic Fuel Injection
Front Suspension	Telescopic fork
Rear Brake	Single disc
ABS	Yes
Width	800 mm
Seat Height	800 mm
Wheelbase	1, 580 mm
Fuel Capacity	12.8 liters
Top Speed	160 km/h
Engine Type	Liquid-cooled, 4-stroke, 4-valve, SOHC
Displacement	499cc
Transmission	CVT
Rear Suspension	Double swing
Front Brake	Dual Discs
