-37-
(4) SPECIFICATIONS
Engine Type
2-stroke single
cylinder
Overall Length 1883 mm
Displacement 49.4cc Overall Width 690 mm
Bore x Stroke 39x41.4 mm Overall Height 1085 mm
Compression Ratio 7.31 Dry Weight 86 kg
Max. Output 3.6 kw/rpm Wheel Base 1307 mm
Max. Torque 0.5/6000 kg/rpm Tire Size
FR:110/70-12
RR:120/70-12
Idle Speed 2000 rpm Fuel Type
#92 or 95 nonleade
gasoline
Transmission Type Non-stage transmission Oil Tank Capacity N
Clutch Dry Multi-Disc Clutch Fuel Tank Capacity 4.9 liter
Ignition C.D.I. Engine Oil Type N
Starting System
Starting motor and
kick starter
Gear Oil Type # 90
Spark Plug BR8HSA Battery 12V4AH
