Kyocera ECOSYS M2135dn User Manual

2-15
Installing and Setting up the Machine > Login/Logout
Login/Logout
If you are setting a function that requires administrator rights, or if user login administration is enabled, you must enter
your login user name and login password.
Login
1
Enter the login user name.
1 If the login screen is displayed during operations, select "Login User Name" and select the
[OK] key.
2 Enter the login user name using the numeric keys and select the [OK] key.
2
Enter the login password.
1 Select "Login Password" and select the [OK] key.
2 Enter the login password and select the [OK] key.
3
Select [Login].
NOTE
The factory default login user name and login password are set as shown below.
You will be unable to login if you forget your login user name or login password. In this event, login with administrator
privileges and change your login user name or login password.
NOTE
• If [Netwk Authentic.] is selected as the user authentication method, [Menu] is
displayed. Select [Menu] and select [Login Type] and then it is possible to select the
authentication destination as [Local Authentic.] or [Netwk Authentic.].
•Select [Menu] and select [Domain] and then it is possible to select from the domains
registered.
NOTE
If Login Operation is [Select Character], then the screen is displayed to enter details by
selecting from the characters on the message display.
Function Defaults (page 8-28)
Character Entry Method (page 11-8)
Character Entry Method (page 11-8)
Model Name Login User Name Login Password
ECOSYS M2135dn/ECOSYS M2635dn/
ECOSYS M2635dw
3500 3500
ECOSYS M2040dn/ECOSYS M2540dn/
ECOSYS M2540dw
4000 4000

Kyocera ECOSYS M2135dn Specifications

General

Color	No
N-up printing	2, 4
Duplex printing	Yes
Print technology	Laser
Duplex printing mode	Auto
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17.5 ppm
Custom media width	70 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	-
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size), Oficio (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (ready)	21 W
Power consumption (sleep)	1 W
Power consumption (standby)	11 W
Power consumption (printing)	535 W
Power consumption (average operating)	661 W
Energy Star Typical Electricity Consumption (TEC)	1.47 kWh/week
Memory type	DDR2
Memory slots	1
Processor family	ARM Cortex-A9
Compatible memory cards	SD
Maximum internal memory	1280 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	53.5 dB
Sound pressure level (quiet mode)	50.2 dB
Sustainability certificates	ENERGY STAR
Display	LCD
Certification	TÜV/GS, CE, ISO 9001, ISO 14001
Product color	White
Market positioning	Business
Display number of lines	5 lines
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Total output capacity	- sheets
Maximum input capacity	800 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	50 sheets
Printing colors	Black
Duplex functions	Print
Maximum duty cycle	50000 pages per month
Recommended duty cycle	2000 - 50000 pages per month
Replacement cartridges	TK-1150 (3.000 pagina's)
Page description languages	PCL 5e, PCL 6, PCL XL, PJL, PostScript 3
Cabling technology	10/100/1000Base-T(X)
Security algorithms	HTTPS, IPPS, IPSEC, SNMP, SSL/TLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	2
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	6.9 s
Copy speed (black, normal quality, A4)	35 cpm
Scan to	E-mail, FTP, SMB, TWAIN, USB, WIA
Scan drivers	TWAIN, WIA
Scan speed (black)	40 ppm
Scan speed (color)	23 ppm
Image formats supported	JPEG, TIF
Document formats supported	PDF, XPS
Cartridge type	TK-1150
Operating altitude	0 - 3500 m
Non-operating altitude	0.6 - 15000 m
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Package depth	555 mm
Package width	541 mm
Package height	572 mm
Package weight	25000 g
Cables included	AC
Included cartridge capacity (black)	1000 pages
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	267 mm
