2P7/2R0/3PN-3
2-2-9
1. Paper feed clutch (PFCL) ..................... Primary paper feed from cassette.
2. Registration clutch (RCL)...................... Controls the secondary paper feed.
3. Developer clutch (DEVSCL) ................. Controls the drive of the developer.
4. Paper conveying clutch (PCCL)............ Controls the paper conveying.
5. Duplex clutch (DUCL) ........................... Controls the drive of the duplex feed roller.
6. MP solenoid (MPSOL) .......................... Controls the MP bottom plate.
7. Feedshift solenoid (FSSOL).................. Operates the feedshift guide.
8. LCD (LCD) ............................................ LCD display. Displays an operating state.
9. Cleaning lamp (CL)............................... Eliminates the residual electrostatic charge on the drum.
10. Fuser heater 1 (FUH1).......................... Heats the heat roller.
11. Fuser heater 2 (FUH2).......................... Heats the heat roller.
12. Fuser thermostat 1 (FUTS1)................. Prevents overheating of the heat roller.
13. Fuser thermostat 2 (FUTS2)................. Prevents overheating of the heat roller.
List of correspondences of other names
No. Name used in service manual Name used in parts list Part.No.
1 Paper feed clutch (PFCL)
PARTS CLUTCH 20-2W Z35R
(RARTS DRIVE FEED ASSY SP)
302LV9416_
(302P79415_)
2 Registration clutch (RCL)
CLUTCH 50 Z35R 302KV4404_
3 Developer clutch (DEVSCL)
4 Paper conveying clutch (PCCL)
PARTS CLUTCH 20-2W Z35R -
5 Duplex clutch (DUCL)
6 MP solenoid (MPSOL)
RARTS DRIVE FEED ASSY SP 302P79415_
7 Feedshift solenoid (FSSOL)
--
8 LCD (LCD)
PARTS PWB ASSY PANEL SP 302P79413_
9 Cleaning lamp (CL)
-
(DK-7300)
-
(302P79306_)
10 Fuser heater 1 (FUH1)
-
(FK-7300)
-
(302P79302_)
11 Fuser heater 2 (FUH2)
12 Fuser thermostat 1 (FUTS1)
13 Fuser thermostat 2 (FUTS2)
