Kyocera FS-4200DN User Manual

Operation Panel
4-54
Network (Network settings)
This printer supports TCP/IP and TCP/IP (IPv6) protocols.
IP is an abbreviation for Internet Protocol. This printer routinely uses the TCP/IP (IPv4) protocol, but provides a separate
setting for the next-generation IP, IPv6.
TCP/IP (IPv4) uses 32-bit IP addresses, but the rapid growth in the number of Internet users has resulted in a shortage of
IP addresses. IPv6 was developed to expand the range of available IP addresses by using 128-bit IP addresses.
The options available in the Network settings are as follows:
• TCP/IP (Enable/Disable TCP/IP)...4-54
• IPv4 Setting (TCP/IP IPv4 settings)...4-55
• IPv6 Setting (TCP/IP IPv6 settings)...4-58
• Protocol Detail (Detailed settings for the network protocol)...4-60
• Restart Network (Restarting the network card)...4-61
1 Press [Menu].
2 Press U or V to select Network.
3 Press [OK]. The Network menu screen appears.
4 Select TCP/IP Settings and press [OK]. The TCP/IP Settings
menu screen appears.
TCP/IP (Enable/Disable TCP/IP)
The TCP/IP system refers to the Internet system, which has a 5-layer structure consisting of the interface layer, link layer,
network (IP) layer, transport (TCP/UDP) layer and application layer.
The interface layer is a key layer in the TCP/IP system that provides an abstracted interface that is not dependent on the
link (communication line: frame relay or Ethernet, etc.) to the IP module (IP layer). This means that the IP module can use
this abstracted interface (which is not dependent on the link type) to exchange IP packets back and forth with the link layer.
1 In the TCP/IP Settings menu, press U or V to select TCP/IP.
2 Press [OK]. The TCP/IP screen appears.
Note Check with your network administrator when selecting the network setting. After all network related settings
have been done, restart the network. Refer to Restart Network (Restarting the network card) on page 4-61. This is
mandatory to make the settings effective!
When Command Center RX is used, network parameters and security settings can be conveniently changed and
checked from your PC. For more information, refer to the Command Center RX User Guide.
Network: a b
********************-
2 Restart Network
[ Exit ]
1 TCP/IP Settings
TCP/IP Settings: a b
********************-
2 IPv4 Setting
3 IPv6 Setting
[ Exit ]
1 TCP/IP
TCP/IP: a b
1 Off
********************-
2 *On

Kyocera FS-4200DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	50 ppm
Printing colors	Black
Maximum duty cycle	250000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter XL24E, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Total input capacity	600 sheets
Total output capacity	- sheets
Maximum input capacity	2600 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet, Parallel, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Processor model	465
Processor family	PowerPC
Compatible memory cards	SD, SDHC
Maximum internal memory	1280 MB
Sound power level (standby)	27.3 dB
Sound pressure level (printing)	54.4 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	12.8 W
Power consumption (printing)	677 W
Power consumption (PowerSave)	1.6 W
Sustainability certificates	Blue Angel, ENERGY STAR
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks

Weight and Dimensions

Depth	416 mm
Width	380 mm
Height	320 mm
